Accessories for KHS

Aerator set for KHS Hygiene Flush Box PRO, PURE and LITE

figure 689 04 019

wetted metal parts made from dezincification-free and corrosion-resistant gunmetal, resistant to aggressive water, stainless steel and drinking water-approved plastics
pressure independent limitation of flow
free from dead spots
plastic parts with KTW and W 270 certification
operating pressure PN 10
5l/min,10l/min,15l/min
a flow limiter 10l/min is pre-assembled
all functional components can be maintained without tools
according to UBA (Federal Environmental Agency) valuation basis

cover for KHS HS2^® hygiene flushing box

figure 689 07 001

CONTROL-PLUS flow measurement valve for KHS HS2^® hygiene flushing box

figure 689 4G 001

for optional flow measurement in the KHS HS2® hygiene-flushing box
wetted metal parts made from dezincification-free and corrosion-resistant gunmetal, resistant against aggressive water
for installation in KHS HS2^® hygiene-flushing box
free from dead spots

connection set surface-mounted CAN bus for KHS HS2^® hygiene flushing box

figure 689 06 001

connection set flush-mounted CAN bus for KHS HS2^® hygiene flushing box

figure 689 06 002

BMS connecting cable via digital I/O for KHS HS2^® hygiene flushing box

figure 689 05 001

for connecting KHS HS2^® hygienic flushing box to the KHS LOGIC control system or to the building management system (BMS) via digital I/O
5 m connection cable

service set (4, 10, 15 l/min) for KHS HS2^® hygiene flushing box

figure 689 99 001

Connection-set

figure 619 01 001

for connecting the KHS CoolFlow chiller, figure 618 01 and of the KHS Cool Flow cooler, figure 610 01
for shut off for maintenance and repair
selected components suitable for both KHS CoolFlow chiller 4.7kW (1.6–5.6) and 7.6kW (2.0–10.0)
consisting of: two pipework compensators G 1, one safety valve Rp 1/2 x Rp 3/4, 6 bar, one double nipple R 1/2, two reducing T-pieces Rp 1 x Rp 1/2, two shut-off valves Rp 1, two shut-off valves Rp 1 with drain plugs on both sides, five extensions for pressure gauges and drain valves G 1/4, three pressure gauges with vertical connection G 1/4, two drain valves G 1/4 x G 3/4, one strainer Rp 1, two double nipples R 1, one diaphragm expansion vessel 12 litres, R 1/2, one screw connection R 1/2 x Rp 1/2, one manual regulating valve Rp 1, four ball valves with extended T-handle
wetted parts made of gunmetal and drinking-water-approved plastics
according to UBA (Federal Environmental Agency) valuation basis

Vibration damper set for chiller

figure 619 02 000

vibration damper set for the KHS CoolFlow chiller for body and vibration isolation
consisting of 4 square mounting bases with die-cast-aluminium device fastening with rubber vibration element in between
incl. screws and washers
dimensions (H/W/D) mm 48/65/65

AC/DC converter

figure 686 01 001

for the operation of the KHS full flow stop valve with spring-reset servo drive 24 V DC with 24 V AC supply voltage figur 686 01
for installation next to the actuated valve

KHS BACnet Gateway L for MASTER 2.0/2.1

figure 686 02 023

interface device for the KHS MASTER 2.0/2.1 mini control system for connection to the building management system
protocol translation into in BACnet IP/MSTP
for flushing systems with up to 24 slaves
LAN RJ45 10/100 MBit/s Ethernet
installation on DIN TS35 top-hat rail in accordance with EN60715

KHS BACnet Gateway XL for MASTER 2.0/2.1

figure 686 02 024

interface device for the KHS MASTER 2.0/2.1 mini control system for connection to the building management system
protocol translation into in BACnet IP/MSTP
for flushing systems with up to 62 slaves
LAN RJ45 10/100 MBit/s Ethernet
installation on DIN TS35 top-hat rail in accordance with EN60715

Modbus TCP/IP licence for MASTER 2.0/2.1

figure 99 3590

licence code for activating the Modbus TCP/IP protocol on the KHS MASTER 2.0/2.1 mini control system
enables connection to the building management system via Modbus TCP/IP
license code can be obtained with MASTER 2.0/2.1 serial number by calling +49 (0) 2761 891-556 or e-mail to Lizenz@kemper-group.com

Reversible cover against unauthorised access for KHS Hygiene Flush Box PRO/PURE/LITE

figure 689 04 026
